– 19 –
Item
No. Code No. Part Name Q’ty
61 949-864 Roll Pin D3x22 1
62 949-865 Roll Pin D3x28 3
63 882-922 Lock Knob 1
64 959-148 Steel Ball 1
65 882-923 Lock Spring 1
66 881-827 Hook 1
67 880-881 Machinr Screw 1
68 877-699 Head Valve O-Ring 1
69 —— Valve Bushing(B) 1
70 878-885 O-Ring(S-18) 1
71 878-925 O-Ring 2
72 880-672 Valve Piston(B) 1
73 878-887 O-Ring 1
74 878-884 Plunger O-Ring 1
75 882-921 Plunger(A) 1
76 878-888 O-Ring 1
77 882-920 Valve Bushing(A) 1
78 880-319 Shsft Ring 2
79 872-645 O-Ring(P-9) 1
80 880-330 O-Ring(P-21) 1
81 882-673 Feed Piston 1
82 882-883 Feed Spring 1
83 877-711 Dumper 1
84 880-331 Feed Piston Cover 1
85 878-305 Magazine Bushing 1
86 939-555 Retaining Ring for D28 Hole 1
87 882-907 Sleeve 1
88 882-899 Pushing Lever Cover(A) 1
89 882-901 Protector(B) 1
90 881-825 Pin 2
91 882-903 Magazine 1
92 877-826 Feeder Shaft Ring 2
93 882-904 Magazine Cover 1
94 —— Label 1
95 881-003 Holder Cap(A) 1
96 880-398 Ratchet Spring 1
97 882-906 Nail Holder 1
98 878-791 Roll Pin D2.5x12 1
99 882-905 Holder Shaft 1
100 881-826 Spring 1
101 949-757 Hex.Socket Hd. Bolt M5x20 1
102 880-658 Nail Guide Shaft 1
103 882-877 Nail Stopper(A) 1
104 882-878 Nail Stopper Spring 1
105 882-876 Nail Guide 1
106 880-318 Guide Lock 1
107 880-446 Spring 1
108 882-680 Nail Stopper(B) 1
109 880-494 Stopper Spring 1
110 880-413 Hex.Socket Hd. Bolt M4x10 1
111 882-880 Cover 1
112 882-879 Nail Guide Cover 1
113 882-881 Sleeve(B) 1
114 880-630 Hex.Socket Hd. Bolt M4x12 1
115 882-902 Magazine Ass’y 1
501 877-153 Oiler 1
502A 875-769 Eye Protector 1
503 880-678 Nose Cap(A) 1
504 880-517 Case 1
Item
No. Code No. Part Name Q’ty
1 949-657 Hex.Socket Hd. Bolt M6x12 1
2 882-919 Plate 1
3 882-917 Top Cover 1
4 882-918 Muffler 1
5 882-916 Protector(A) 1
6 949-662 Hex.Socket Hd. Bolt M5x25 4
7A 882-911 Exhaust Cover 1
8 882-915 Packing(A) 1
9 882-914 Head Bamper 1
10 882-913 Head Valve Spring 1
11 876-796 O-Ring(P-22) 1
12 882-912 Head Valve(A) 1
13 878-863 O-Ring(S-70) 1
14 882-910 Cylinder Plate 1
15 882-874 O-Ring(S-46) 2
16 877-368 O-Ring(P-48) 1
17 882-909 Cylinder 1
18 882-871 Piston O-Ring 1
19 882-872 Piston Ring 1
20 882-870 Piston 1
21 968-643 Retaining Ring for D4 Shaft 1
22 —— Name Plate 1
23A 882-908 Body Ass’y 1
24 —— Decor 1
25 882-873 Piston Bumper 1
26 874-436 O-Ring(P-4) 2
27 882-875 Nose 1
28 880-675 Hex.Socket Hd. Bolt M6x20 4
29 949-770 Roll Pin D4x14 1
30 880-659 Needle Roller 1
31 878-132 Feeder Arm 1
32 —— Feeder Spring 1
33 882-882 Feeder 1
34 882-900 Pushing Lever Cover(B) 1
35 882-884 Pushing Lever 1
36 877-371 Nylon Nut M5 2
37 881-768 Grip Tape(A) 1
38 880-407 Tape 2
39 880-183 O-Ring 1
40A 883-177 Cap 1
41 877-914 Dust Cap 1
42 874-782 Air Plug PT1/4 1
43 882-896 Trigger Piece 1
44 882-897 Spring 1
45 882-895 Trigger Arm(B) 1
46 881-951 Roll Pin D2.5x16 1
47 882-894 Trigger 1
48 882-898 Trigger Spring 1
49 882-885 Pushing Lever Guide 1
50 882-892 Pushing Lever Spring 1
51 882-891 Pushing Lever(C) 1
52 882-889 Adjuster 1
53 880-093 Roll Pin D2x16 1
54 882-890 Adjuster Spring 1
55 882-887 Adjuster Plate(B) 1
56 882-886 Adjuster Plate(A) 1
57 981-317 O-Ring(S-4) 2
58 882-888 Pushing Lever(B) 1
59 872-822 O-Ring(S-5) 1
60 872-971 Retaining Ring for D3 Shaft 1
Parts are subject to change without any obligation on
the part of the HITACHI due to improvements.
