Filter
Top Products
'(*,!'&
$&T(*'
!&!,!'&'/$!&,*%+
/+
• Wire Feed Speed
SConstant Current
.
SConstant Voltage
%/
• Gas Metal Arc welding
+%/
SShielded Metal Arc welding
/
SFlux Core Arc Welding
&*$+*!(,!'&
8A8E4?(;LF<64?8F6E<CG<BA
The LN-25™ PRO is specially engineered to be the
most rugged portable wire feeder available.
Several models of the LN-25™ PRO are offered to
best meet individual welder needs. The Extra Torque
model features additional torque gearing for reliable
feeding of large diameter FCAW wires. All of the mod-
els include a gas solenoid and flow meter for the flexi-
bility to run most wire processes.
The plastic case is molded from a high impact, flame
retardant plastic for durability and low weight. The
patent pending design keeps the internal components
protected and dry.
The heart of the LN-25™ PRO is the 2 roll MAX-
TRAC™ drive. The patented features on the wire
drive offer tool-less changing of the drive rolls and
wire guides for quick spool changes. A tachometer
controlled motor powers the patent pending drive rolls
for smooth, steady feeding without slippage.
The LN-25™ PRO has only two p.c. boards that are
designed to be simple, reliable and easy to service.
8A8E4?HA6G<BA4?8F6E<CG<BA
The LN-25™ PRO as designed is a simple, robust
feeder. Standard features include a calibrated wire
feed speed dial, 2 step/trigger interlock switch, CV-CC
switch, Gas Purge and Cold Feed.
*'%%&(*'+++
• GMAW
• FCAW
(*'++$!%!,,!'&+
• GMAW-P procedures must be qualified by the cus-
tomer.
• Across-the-Arc models are not recommended for
stitch or spot welding.
)-!(%&,$!%!,,!'&+
• The duty cycle of the wire feeder is 325A, 100% and
450A, 60%. Duty cycle is based upon the amount of
welding performed in a 10 minute period.
• The maximum spool size is 45 lb, 12" diameter.
• Maximum FCAW gun length is 15 ft.
• Maximum GMAW gun length is 25 ft.
• Push-pull guns do not work with the wire feeder.
*'%%&('/*+'-*+
• CV-250
• CV-300
• CV-305
• CV-400
• CV-655
• DC-400
• DC-600
• DC-655
• Invertec V-350 PRO
• Invertec V-450 PRO
• Multi-Weld 350
• Ranger 10,000
• Ranger 3 Phase
• Ranger 225
• Ranger 225 GXT
• Ranger 250
• Ranger 250 GXT
• Ranger 305
• SAE-400
• Pipeliner 200G
• Classic 300
• Vantage 300
• Vantage 400
• Vantage 500
• Air Vantage 500
Big Red’s
Eagle 10,000 Plus
Classic’s
