Installing or removing diamond wheel
To install the wheel, first loosen the bolt with the hex wrench
and remove the bolt and the flange. Then mount the wheel,
the flange and the bolt. The wheel should be mounted with
the Makita name on the flange side.
Press the shaft lock so that the wheel cannot revolve. Use
the hex wrench to tighten the bolt securely.
To remove the wheel, follow the installation procedure in
reverse.
CAUTION:
• When installing the wheel, be sure to tighten the bolt
securely.
• Use only the Makita wrench to install or remove the
wheel.
Hex wrench storage
When not in use, store the hex wrench as shown in the figure
to keep it from being lost.
Installing water supply
Attach the tank holder on the tank. The tank holder should be
attached around the portion shown with the dotted line.
Tighten the screw (A) to the extent that the tank can still turn
within the tank holder.
1. Bolt
2. Flange
3. Diamond wheel
1
2
3
003531
1. Hex wrench
2. Shaft lock
1
2
003532
1. Hex wrench
1
001452
1. Tank holder installing portion
2. Tank
3. Screw (B)
4. Screw (A)
5. Tank holder
1
3
4
5
2
003538
