11
Attach the tank holder onto the motor housing. Tighten the
screw (B) securely.
Connect the cap on the end of the polyvinyl tube to the
mouth of the tank. Turn the tank clockwise when making the
connection. Then tighten the screw (A) securely to secure
the tank.
CAUTION:
• If you find the polyvinyl tube is bent like a “V” or has
been strained excessively after installing the water
supply, loosen the screw (B) and adjust the position of
the tank to alleviate the bent, pinched or strained
condition.
Water supply
Remove the cap on the tank and fill through the hole. Recap
the tank. Be sure that the water cock is turned off when filling
the tank with water.
CAUTION:
• When filling the tank with water, be careful not to let the
tool get wet.
OPERATION
Hold the tool firmly. Set the base plate on the workpiece to
be cut without the wheel making any contact. Then turn the
tool on and wait until the wheel attains full speed. Feed water
to the wheel by adjusting the water cock to obtain a gentle
flow of water. Move the tool forward over the workpiece sur-
face, keeping it flat and advancing smoothly until the cutting
is completed. Keep your cutting line straight and your speed
of advance uniform.
For fine, clean cuts, cut slowly. (When cutting glass plate 5
mm (3/16”) thick, cut at about 250 mm/min (9-7/8”/min).
When cutting tile 10 mm (3/8”) thick, cut at about 300 mm/
1. Screw (B)
1
003539
003540
1. Cap
1
003542
1. Base
1
003547
