Top Products
Processes
TIG (GTAW)
Pulsed TIG (GTAW-P)
Stick (SMAW)
Air Carbon Arc (CAC-A)
350: 1/4 in maximum
700: 3/8 in maximum
Input Power 208–575 V, 3- or 1-Phase
Amperage Range 350: 5–350 A
700: 5–700 A
Rated Output 350: 300 A at 32 V, 60% Duty Cycle
700: 600 A at 44 V, 60% Duty Cycle
Weight 350: 135.5 lb (61 kg)
700: 198 lb (90 kg)
Industrial Applications
Precision Fabrication
Heavy Fabrication
Pipe and Tube Fabrication
Aerospace
Aluminum Ship Repair
Anodized Aluminum Fabrication
Quick
Specs
Dynasty
®
350 and 700
TIG/Stick Welding
Power Source
Issued Oct. 2008 • Index No. AD/5.0
The Power of Blue
®
.
Miller Electric Mfg. Co.
An Illinois Tool Works Company
1635 West Spencer Street
Appleton, WI 54914 USA
Web Site
www.MillerWelds.com
International Headquarters
Phone: 920-735-4505
USA FAX: 920-735-4134
Canadian FAX: 920-735-4169
International FAX: 920-735-4125
Power source is warranted for 3 years, parts and labor.
Original main power rectifier parts are warranted for 5 years.
Allows for any
input voltage
hookup (208–575 V) with no manual linking,
providing convenience in any job setting.
Ideal solution for dirty or unreliable power.
NEW!
Meter Calibration allows meters to
be calibrated for certification.
120 V auxiliary power receptacle for
cooling system or small tools.
Wind Tunnel Technology
™
protects internal
electrical components from airborne
contaminants, extending the product life.
Fan-On-Demand
™
power source cooling
system operates only when needed,
reducing noise, energy use and the amount
of contaminants pulled though the machine.
TIGRunner
®
packages feature a
3.5 gallon (13.2 L) cooling system. The
cart is equipped with cylinder carrying
capabilities, filler rod holder, foot pedal
holder, torch and cable holders. A pullout
drawer provides additional storage for torch
consumables and tools. See page 6.
Programmable start parameters allow
independent starting conditions based
on process and memory selections
(amperage, time and polarity).
Program memory features 9 independent
program memories that maintain/save
your parameters.
High-frequency arc starter for
non-contact arc initiation.
Lift-Arc
™
start provides AC or DC arc
starting without the use of high frequency
Auto-Postflow calculates the length of
postflow time based on the amperage setting.
This eliminates the need to independently set
the postflow time for different amperages.
This feature preserves your tungsten and
prevents porosity.
Stick Features (AC/DC)
Tailored arc control (DIG) allows the arc characteristic
to be changed for specific applications and electrodes.
Smooth running 7018 or stiffer, more penetrating 6010.
Hot Start
™
adaptive control provides positive arc starts
without sticking.
AC frequency control adds additional stability when Stick
welding in AC for smoother welds.
AC TIG Features
Independent Amplitude/Amperage
Control allows EP and EN
amperages to be set independently
to precisely control heat input to the
work and electrode.
Extended AC balance (30–99%)
controls the amount of oxide
cleaning (amperage time in EN)
which is essential for high quality
welds on aluminum.
AC frequency (20–400 hz) controls
the width of the arc cone and the
force of the arc.
AC Waveforms
Advance Squarewave, fast
freezing puddle, deep
penetration and fast travel speeds.
Soft Squarewave for a soft
buttery arc with maximum
puddle control and good wetting action.
Sine wave for customers
that like a traditional arc.
Quiet with good wetting.
Triangular wave reduces the
heat input and is good on
thin aluminum. Fast travel speeds.
DC TIG Features
Exceptionally smooth and precise
arc for welding exotic materials.
High-Speed DC TIG Pulse Control
Pulse frequency capable of pulsing
5000 pulses per second. Pulsing
adds arc stability, reduces heat input
and warpage and can increase travel
speeds. Other parameters include
peak amperage, peak time and
background amperage.
Dynasty 700
Dynasty 350
