Dynasty
®
Power Sources
TIGRunner
®
Packages
Complete Packages
6
Packages and Torch Kits
Dynasty
®
350 #907 204 (CSA)
(Auto-Line
208–575 VAC)
Dynasty
®
350 #907 204-02-1 (CE)
(Auto-Line
380–575 VAC)
8 ft (2.4 m) primary cord, (2) international
(Dinse 50) connectors, and CD-ROM Setup
and Simulator.
Note: TIG torch adapter must be ordered separately.
Dynasty
®
700 #907 101 (CSA)
(Auto-Line
208–575 VAC)
Dynasty
®
700 #907 101-02-1 (CE)
(Auto-Line
380–575 VAC)
(2) thread lock weld cable connectors
(#225 029), (1) water-cooled thread lock
torch adapter (#225 028) for #18 or #20
torches, and CD-ROM Setup and Simulator.
Note: Primary cord and TIG torch must be ordered
separately.
Dynasty 350 TIGRunner
®
#907 204-01-1 (CSA)
Completely assembled.
Package includes:
Dynasty
®
350 (#907 204)
RFCS-14 HD foot control
Coolmate
3.5 Coolant System
Cart with the following features:
single cylinder rack, foot pedal holder,
(3) cable/torch holders, (2) TIG electrode
filler holders and a convenient drawer
for tungsten and consumable storage
Note: Torch package and coolant must be ordered
separately.
Dynasty 700 TIGRunner
®
#907 101-01-1 (CSA)
Completely assembled.
Package includes:
Dynasty
®
700 (#907 101)
RFCS-14 HD foot control
Coolmate
3.5 Coolant System
Cart with the following features:
single cylinder rack, foot pedal holder,
(3) cable/torch holders, (2) TIG electrode
filler holders and a convenient drawer
for tungsten and consumable storage
Note: Torch package and coolant must be ordered
separately.
Dynasty 350 Complete
#951 074 (CSA)
Completely assembled.
Package includes:
Dynasty
®
TIGRunner
®
(#907 204-01-1)
25 ft (7.6 m) Weldcraft CS310
water-cooled torch
Torch cable cover
CS310AKC torch accessory kit includes
shielding cups, collets, collet bodies,
and 2% cerium tungsten electrodes
(1/16, 3/32, and 1/8 in)
Smith regulator/flowmeter HM2051A-580
12 ft (3.7 m) rubber gas hose (regulator
to machine)
Water-cooled Dinse torch adapter
15 ft (4.6 m) 1/0 weld lead with clamp
(work or ground lead) and Dinse
connector
4 gallons of pre-mixed low-conductivity
coolant (#043 810)
Dynasty 700 Complete
#951 075 (CSA)
Completely assembled.
Package includes:
Dynasty
®
700 TIGRunner (#907 101-01-1)
25 ft (7.6 m) Weldcraft WP18SC
water-cooled torch
Torch cable cover
AK18C Torch Accessory Kit includes
shielding cups, collets, collet bodies and
2% cerium tungsten electrodes (3/32,
1/8 and 5/32 in)
Smith regulator/flowmeter H1954D-580
12 ft (3.7 m) rubber gas hose (regulator
to machine)
Water-cooled thread lock torch adapter
12 ft (3.7 m) 4/0 weld lead with clamp
(work or ground lead)
4 gallons of pre-mixed low-conductivity
coolant (#043 810)
