CR-W402UA
Specifications
❐ General
Power Supply: 12 V DC (11 V-16 V) test Voltage 14.4 V, Negative @ ground
Current consumption: Less than 2.5 A (0.5 W 4-speaker)
Maximum Power Output: 37 W × 4 channels at 400 Hz, Volume Control maximum
Tone adjustment range:
Bass: ± 12 dB at 100 Hz
Treble: ± 12 dB at 10 kHz
Power Output: 18 W per channel into 4 ohms, 40 to 30,000 Hz at 3 % THD
Suitable Speaker Impedance: 4 – 8 Ω
Dimensions (W × H × D): 178 × 50 × 150 mm {7" × 1-15/16" × 5-7/8"}
Weight: 0.85 kg {1.87 lbs.}
❐ FM Stereo Radio
Frequency Range: 87.9 – 107.9 MHz
Usable Sensitivity: 12 dBf (1.1 µV/ 75 Ω, S/N 30 dB)
50 dB Quieting Sensitivity: 17 dBf (1.8 µV/ 75 Ω)
Frequency Response: 30 – 15,000 Hz ±3 dB
Alternate Channel Selectivity: 75 dB
Stereo Separation: 35 dB at 1 kHz
Signal/Noise Ratio: 70 dB (Mono)
❐ AM Radio
Frequency Range: 530 kHz – 1,710 kHz
Usable Sensitivity: 28 dB/µV (25 µV, S/N 20 dB)
❐ Weather Band Radio
Frequency Range: 162.400 – 162.550 MHz
Usable Sensitivity: 3 dB/µV (S/N 20 dB)
Signal/Noise Ratio (40 dB/µV): 50 dB
Above specifications comply with EIA standards.
Note: Specifications and the design are subject to modification without notice due to improvements in technology.
Power Output:
16 W RMS x 4 Channels at 4 Ω and ≤ 1%
THD+N
Signal to Noise Ratio:
70 dBA (reference: 1 W into 4 Ω)
