Bit-locking function
1. With the trigger switch not engaged
and a screwdriver bit locked in
place, the tool can be used as a
manual screwdriver (up to 22.6 Nm,
230 k
f-cm, 199 in-lbs).
There will be a little play in the
chuck, but this is not a malfunction.
2. This feature is handy for tightening
screws that require more torque
than the maximum torque of the
driver (position on the clutch), for
confirming the tightness of a screw
or to loosen an extremely tight
screw.
Speed Selection
Choose a low or high speed to suit
the use.
The more the speed control trigger is
pulled, the higher the speed becomes.
No load speed Torque
LOW 80 - 550/min (rpm) Strong
HIGH 300 - 2000/min (rpm) Weak
CAUTION: Check the speed selector
switch before use.
Use at low speed when
strong force is needed dur-
ing operation. (Using at
high speed while a strong
force is applied may cause
a motor breakdown.)
Do not operate the
speed selector switch
(LOW-HIGH) while pull-
ing on the speed control
trigger. This can cause
the rechargeable battery
to wear quickly or dam-
age the internal mecha-
nism of the motor.
*
See appendix for “RECOM-
MENDED SPEED SELEC-
TION”.
For Appropriate use of Battery
pack
Ni-MH Battery pack EY9231
Charge the Ni-MH battery fully be-
fore storage in order to ensure a
longer service life.
The ambient temperature range is
between 0°C (32°F) and 40°C
(104°F).
If the battery pack is used when the
battery temperature is below 0°C
(32°F) the tool may fail to function
properly. In that case, charge the
battery until charging is completed
for appropriate functioning of the
battery.
When operating with a Ni-MH bat-
tery pack, make sure the place is
well-ventilated.
Battery Pack Life
The rechargeable batteries have a
limited life. If operation time becomes
extremely short after recharging,
replace the battery pack with a new
one.
Note: Use under extremely hot or
cold conditions will reduce
operating capacity per charge.
Charging
Note: When you charge the battery
pack for the first time, or after
prolonged storage, charge it
for about 24 hours to bring the
batteries up to full capacity.
EY0230
1. Plug the charger into the AC outlet.
Note: Sparks may be produced
when the plug is inserted into
the AC power supply, but this
is not a problem in terms of
safety.
2. Insert the battery pack firmly into
the charger.
