Bit-locking function
1. With the trigger switch not engaged
and a screwdriver bit locked in place,
the tool can be used as a manual
screwdriver (up to 22.6 Nm, 230 k
f-cm, 199 in-lbs).
There will be a little play in the chuck,
but this is not a malfunction.
2. This feature is handy for tightening
screws that require more torque than
the maximum torque of the driver (po-
sition on the clutch), for confirming
the tightness of a screw or to loosen
an extremely tight screw.
NOTE:
When the brake operates, a
braking sound may be heard.
This sound indicates engagement
of the bit lock.
CAUTION: To eliminate excessive
temperature increase of the
tool surface, do not operate
the tool continuously using
two or more battery packs.
Tool needs cool off time
before switching to another
pack.
D o n o t c l o s e u p v e n t
holes on body sides of the
bo dy du ri n g op e ra t io n.
Otherwise, the machine func-
tion is adversely affect
ed to
cause a failure
Do NOT strain the tool(motor).
This may cause damage to
the unit.
Use the machine in such
a way as to prevent the air
from the body vent holes
from blowing directly onto
your skin. Otherwise, you
may get burnt.
When operating with a
Ni-MH battery pack, make
sure the place is well-venti-
lated.
Speed Selection
Choose a low or high speed to suit
the use.
The more the speed control trigger is
pulled, the higher the speed becomes.
No load speed Torque
LOW 80 - 550/min (rpm) Strong
HIGH 300 - 2000/min (rpm) Weak
CAUTION: Check the speed selector
switch before use.
Use at low speed when
strong force is needed dur-
ing operation. (Using at
high speed while a strong
force is applied may cause
a motor breakdown.)
Do not operate th e
speed selector switch
(LOW-HIGH) while pull-
ing on the speed control
trigger. This can cause
the rechargeable battery
to wear quickly or dam-
age the internal mecha-
nism of the motor.
*
See appendix for “RECOM-
MENDED SPEED SELEC-
TION”.
For Appropriate use of Battery
pack
Ni-MH Battery pack EY9251
Charge the Ni-MH battery fully before
storage in order to ensure a longer ser-
vice life.
The ambient temperature range is be-
tween 0°C (32°F) and 40°C (104°F).
If the battery pack is used when the
battery temperature is below 0°C
(32°F) the tool may fail to function
properly. In that case, charge the bat-
tery until charging is completed for ap-
propriate functioning of the battery.
When operating with a Ni-MH battery
pack, make sure the place is well-
ventilated.
Battery Pack Life
The rechargeable batteries have a
limited life. If operation time becomes
