. LAMP INDICATIONS
Red Flashing
Red Lit
Flashing quickly
Orange Lit
Orange Flashing
Charger is plugged into a wall outlet.
Ready to charge.
Now charging
Charging is completed.
Battery pack is warm. Charging will begin
when temperature of battery pack drops.
Charging is not possible. Clogged with
dust or malfunction of the battery pack.
.
MAINTENANCE
Use only a dry, soft cloth for wiping the unit. Do not use a damp cloth, thinner, ben-
zine, or other volatile solvents for cleaning.
BATTERY RECYCLING
ATTENTION:
A nickel metal hydride battery that is recyclable powers the product you have pur-
chased.
Please call 1-800-8-BATTERY for information on how to recycle this battery.
. ACCESSORIES
Use only bits suitable for size of drill’s chuck.
RECOMMENDED SPEED SELECTION
CAUTION: USE AT LOW SPEED WHEN STRONG FORCE IS NEEDED
DURING OPERATION.
(Using at high speed while a strong force is applied may cause a
motor breakdown.)
Use the following as a guide to select low or high speed for the job.
EY6950
DRILLING
SCREW
TIGHTENING
MATERIAL/
CONDITION
MORTAR /
BRICK
WOOD /
YELLOW PINE
METAL METAL HOLE SAW
Wood screws
Thickness: 40 mm
(1-37/64") or less
Cold-rolled steel plate (SPC)
Thickness: 1.6 mm (1/16”) or less
HIGH
ø 10 mm (3/8")
or less
Not used
ø 6.5 mm (1/4")
or less
Not used
ø 4 mm (5/32")
or less
LOW
ø 13 mm (1/2")
or less
(Slow operation)
ø 36 mm (1-27/64")
or less
ø 13 mm (1/2")
or less
ø 34 mm (1-11/ 32")
or less
ø 6.8 mm (17/64")
or less
