15 - ENG N000732
7. Replacehoseandnewhoseclamp.
8. PerformtheBreakinProcedure.See"BreakinProcedure"intheOperation
section.
TO REPLACE REGULATOR
1. Releaseallairpressurefromairtank.See"ToDrainTank"intheMaintenance
section.
2. Unplug unit.
3. Using an adjustable wrench
Safety
Valve
Regulator
Manifold
Quick
Connects
Gauges
Hose
Clamp
remove the gauges, quick
connect, and safety valve from
the regulator manifold.
4. Removethehosebyremoving
the hose clamp. NOTE: The
hose clamp is not reusable.
You must purchase a new hose
clamp, purchase a standard
hose clamp at a local hardware
store.
5. Using an adjustable wrench
remove the regulator manifold.
6. Apply pipe sealant to new
regulator manifold and assemble, tighten with wrench.
7. Reapplypipesealanttogauges,quickconnect,andsafetyvalve.
8. Reassembleallcomponentsinreverseorderofremoval.Makesuretoorient
gauges to read correctly and use wrenches to tighten all components.
