20 - ENGD23269
PROBLEM
CAUSE
CORRECTION
Possible defect in safe-
ty valve.
Operate safety valve manually by
pulling on ring. If valve still leaks,
it should be replaced.
Defective check valve. Remove and clean, or replace.
Knocking Noise.
Compressor is not
supplying enough
air to operate
accessories.
Prolonged excessive use
of air.
Compressor is not large
enough for air require-
ment.
Hole in hose.
Check valve restricted.
Air leaks.
Restricted air intake filter
Decrease amount of air usage.
Check the accessory air require-
ment. If it is higher than the
SCFM or pressure supplied by
your air compressor, you need a
larger compressor.
Check and replace if required.
Remove and clean, or replace.
Tighten fittings.
Clean or replace air intake filter.
Do not operate the air compressor
with the filter removed. Refer to
the “Air Filter” paragraph in the
“Maintenance “ section
Loose pulley Tighten pulley set screw,
70-80 in.-lbs.
Compressor mounting
screws loose
Tighten mounting screws,
15-20 ft.-lbs.
Loose flywheel Tighten flywheel screw,
15-20 ft.-lbs.
Loose belt
Loosen wingnut and then tighten
wingnut until it contacts the wash-
er, plus one turn.
Carbon build-up in
pump
Have checked by a Trained
Service Technician.
Belt to tight Loosen wingnut and then tighten
wingnut until it contacts the wash-
er, plus one turn.
Loose belt.
Loosen wingnut and then tighten
wingnut until it contacts the wash-
er, plus one turn.
