INTERIOR CUTTING (FIG. X)
1. Lay out the design on the workpiece (1). Drill a 1/4 in.
(6.4 mm) hole in the workpiece.
2. Release the quick release tension lever (2), remove
the blade (3). Refer to BLADE REMOVAL AND
INSTALLATION.
3. Place the workpiece on the saw table with the
workpiece hole (4) over the access hole in the table
(5).
4. Install the blade (3) through the hole in the workpiece
and lower the quick release tension lever (2).
5. Follow the process, items 3-8, under FREEHAND
CUTTING OPERATIONS.
6. When finished making the interior scroll cuts simply
turn the scroll saw OFF, remove the blade from the
blade holder and remove the workpiece from the
table.
Fig. X
5
1
4
2
3
