DM9161B
10/100 Mbps Fast Ethernet Physical Layer Single Chip Transceiver
35 Final
Version: DM9161B-12-DS-F01
January 31, 2008
9. DC and AC Electrical Characteristics
9.1 Absolute Maximum Ratings (25°C)
Symbol Parameter Min. Max. Unit Conditions
DVDD, Supply Voltage -0.3 3.6 V
VIN DC Input Voltage (VIN) -0.5 5.5 V
VOUT DC Output Voltage(VOUT) -0.3 3.6 V
Tstg Storage Temperature Rang (Tstg) -65 +150
°C
LT Lead Temp. (TL, Soldering, 10 sec.) - +260
°C
DM9161BEP
9.2 Operating Conditions
Symbol
Parameter
Min.
Typ. Max.
Unit
Conditions
DVDD Supply Voltage 3.135 3.300 3.465 V
TA Ambient Temperature 0 - +70
°C
100BASE-TX - 130 - mA 3.3V
10BASE-T TX. - 168(61) - mA 3.3V(power
saving)
Auto-negotiation - 58 - mA 3.3V
PD
(Power Dissipation)
Power Down Mode - 17 - m
A 3.3V
Comments
Stresses above those listed under “Absolute
Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only. Functional
operation of this device at these or any other
conditions above those indicated that in the
operational sections of this specification is not implied.
Exposure to absolute maximum rating conditions for
extended periods may affect device reliability.
