DM9161B
10/100 Mbps Fast Ethernet Physical Layer Single Chip Transceiver
43 Final
Version: DM9161B-12-DS-F01
January 31, 2008
9.4.21 Magnetic Selection Guide
Refer to Table 2 for transformer requirements.
Transformers, meeting these requirements, are
available from a variety of magnetic manufacturers.
Designers should test and qualify all magnetic before
using them in an application. The transformers listed in
Table 2 are electrical equivalents, but may not be
pin-to-pin equivalents.
Manufacturer Part Number
Pulse Engineering PE-68515, H1102
YCL PH163112, PH163539
DELTA LFE8505-DC , LFE8563-DC, LFE8583-DC
GTS FC-618SM
MACOM HS9016, HS9024
