21
Getting Started
Figure 2-7 Slide a PC Card into the AP
5. Attach one end of an Ethernet cable to the AP's Ethernet port and the other end to a network hub or switch.
6. Connect the unit to a power source.
7. Wait for the power LED to turn green before proceeding.
Figure 2-8 Power LED turns green when the unit is operational
8. Conduct a Site Survey to determine the best location for your device.
9. Once you have chosen a final location for your unit, mount the wall bracket and the processor module and place
the cover onto the unit as shown.
Figure 2-9 Wall mounting the AP
