Page 14 For technical questions, please call 1-800-444-3353. SKU 68001
NOTICE
Clean the Sprayer IMMEDIATELY after use. Delayed or inadequate cleaning will permanently clog the
Spray Gun. Warranty void if sprayer is not properly cleaned immediately after every use.
Painting
Before painting, ensure the Sprayer has been primed
(see Priming and Startup steps) and verify
that Nozzle Tip is aligned properly.
Note: Remove or cover objects that you want
to protect from overspray and paint mist.
1. Once primed, adjust nozzle to Spray setting.
2. Start spraying at the lowest setting on the Pressure
Control Knob and increase pressure as needed by
turning clockwise to create a good spray pattern.
Hi Spray Low Spray Prime/Clean Roll
Painting Techniques
Before painting, ensure the Sprayer has been primed
(see Priming and Startup steps) and
verify that Nozzle Tip is aligned properly.
Keep the gun approximately 1 foot from the surface.
1. Keep gun straight and move arm across at a steady
rate while staying one foot from the surface.
2. Do not fan the gun or paint will be uneven.
3. Overlap strokes by half, always aim
stroke at bottom edge of last stroke.
Overlap
Strokes
