Page 20 For technical questions, please call 1-800-444-3353. SKU 68001
Part Description Qty
1 Spray Gun 1
2 Paint Hose 1
3 Base Frame 1
4 Hex Bolt (M6x4) 2
5 Pressure Relief Valve Label 1
6 Housing Cover 1
7 Output Gear Bushing 2
8 Rolling Bearing 1
9 Output Pole 1
10 Gear 1
11 Middle Gear Bushing 2
12 Output Gear 1
13 Pin (5x12) 2
14 Screw 1
15 Paint Outlet 1
16 O-Ring (10x1.8) 1
17 Output Spring 1
18 Mandrel 1
19 Steel Ball (6.4) 1
20 Seal Seat 1
21 Output Pusher 1
22 Pump Body 1
23 Nylon Washer 1
24 Insert Block 1
25 Pressure Relief Valve 1
26 Nylon Ring 1
27 O-Ring (5x1.8) 1
28 Pressure Relief Pole 1
29 Pressure Relief Spring 1
30 Spring Seat 1
31 Pin (3x8) 1
32 Control Valve Seat 1
33 Prime/Spray Valve 1
34 Pin 1
35 Nylon Cable Tie 1
36 Inlet Spring Holder 1
37 Input Spring 1
38 Steel Ball (12.7) 1
39 Input Seal 1
40 Input Washer 1
41 O-Ring (17x1.8) 1
42 Paint Input Adaptor 1
43 Pressure Relief Plug 1
44 Small Clamp 1
45 Large Clamp 1
46 Return Tube 1
47 Suction Tube 1
48 Clip 3
49 Inlet Pipe Lock Ring 1
50 Filtrate Seat Assembly 1
51 Wire label 1
52 Power Cord 1
53 Locking Ring 1
54 Screw (M4x14) 2
Part Description Qty
55 Wire Fastening Seat 1
56 Label 1
57 Hex Bolt (M6x10) 3
58 Housing 1
59 Label 1
60 Motor Assembly 1
61 Power Switch 1
62 Pin (3x12) 1
63 Hex Bolt (M5x14) 4
64 Elastic Washer 4
65 O-Ring (12.5x2.65) 2
66 Joint Stopper 1
67 Position Washer 1
68 Wave Washer 1
69 White Seal 3
70 Black Seal 2
71 Copper Washer 1
72 O-Ring (22.5x1.8) 2
73 Connector 1
74 Copper Guide Bushing 1
75 Piston 1
76 Lock Sleeve 1
77 White Seal 2
78 Pressure Control Pin 1
79 O-Ring (8.8x1.9) 1
80 O-Ring (27x2.4) 1
81 Hex Bolt (M3x10) 1
82 Pressure Seal Cover 1
83 Micro Switch 1
84 Micro Switch Cover 1
85 Pressure Control Switch 1
86 Switch Cover 1
87 Pressure Adjusting Spring 1
88 Spring Pusher 1
89 Pressure Control Label 1
90 Pressure Knob 1
91 Pressure Control Bolt 1
92 Label 1
93 Handle Grip 1
94 Handle 1
95 Hex Bolt (M6x30) 2
96 PCB Supporter 1
97 Wire Connector 1
98 Nylon Cable Tie 1
99 Safety Cover 1
100 PCB Assembly 1
101 Tapping Screw 2
102 Power Cord Fixer 1
103 Hex Bolt (M4x20) 2
104 Cup 1
105 Bolt (M5x20) 1
106 Pole Stopper 1
107 Small Gear Washer 1
Parts List
