WARNING: Fire hazard. Do not store
or carry battery so that metal objects can
contact exposed battery terminals. For
example, do not place battery in aprons,
pockets, tool boxes, product kit boxes,
drawers, etc., with loose nails, screws,
keys, etc. Transporting batteries can
possibly cause fires if the battery terminals
inadvertently come in contact with
conductive materials such as keys, coins,
hand tools and the like. The US
Department of Transportation Hazardous
Material Regulations (HMR) actually
prohibit transporting batteries in commerce
or on airplanes (i.e., packed in suitcases
and carry-on luggage) UNLESS they are
properly protected from short circuits. So
when transporting individual batteries,
make sure that the battery terminals are
protected and well insulated from materials
that could contact them and cause a short
circuit. NOTE: Lithium-Ion batteries should
not be put in checked baggage.
Storage recommendationS
The best storage place is one that is
cool and dry away from direct sunlight and
excess heat or cold.
2. Long storage will not harm the battery
pack or charger.
IMPORTANT CHARGING NOTES
be obtained if the battery pack is charged
battery pack in an air temperature below
This is important and will prevent serious
damage to the battery pack.
2. The charger and battery pack may become
warm to touch while charging. This is a normal
condition, and does not indicate a problem. To
facilitate the cooling of the battery pack after
use, avoid placing the charger or battery pack
in a warm environment such as in a metal
shed, or an uninsulated trailer.
3.
If the battery pack does not charge properly:
plugging in a lamp or other appliance.
connected to a light switch which turns
power off when you turn out the lights.
c. Move charger and battery pack to a
location where the surrounding air
d. If charging problems persist, take
the tool, battery pack and charger to
your local service center.
4. The battery pack should be recharged
when it fails to produce sufficient power on
jobs which were easily done previously.
DO NOT CONTINUE to use under these
conditions. Follow the charging procedure.
You may also charge a partially used pack
whenever you desire with no adverse
affect on the battery pack.
such as, but not limited to, steel wool,
aluminum foil, or any buildup of metallic
particles should be kept away from charger
cavities. Always unplug the charger from
the power supply when there is no battery
pack in the cavity. Unplug charger before
attempting to clean.
water or any other liquid.
WARNING: Shock hazard. Do not
allow any liquid to get inside charger.Never
attempt to open the battery pack for any
reason. If the plastic housing of the
battery pack breaks or cracks, return to
a service center for recycling.
FUNCTIONAL DESCRIPTION
Figure A
3. Shoe
4. Blade clamp release lever
CHARGING PROCEDURE
chargers are designed to
charge
hours depending on the pack being charged.
outlet before inserting the battery pack.
2. Insert the battery pack into the charger
as shown in figure B.
3. The green LED will flash indicating that
the battery is being charged.
4.
The completion of charge is indicated by
the green LED remaining on continuously.
The pack is fully charged and may be used
at this time or left on the charger.
LEAVING THE BATTERY IN
THE CHARGER
The charger and battery pack can be left
connected with the green LED glowing
indefinitely. The charger will keep the
battery pack fresh and fully charged.
INSTALLATION AND REMOVAL OF
THE BATTERY PACK
TO INSTALL BATTERY PACK: Insert
battery pack into the tool until an audible
Figure C). Make sure
battery pack is fully seated and fully
latched into position.
Description Catalog #
These products use the batteries and chargers listed in the chart below.
20v Max** Lithium-Ion Battery: LBXR20
20v Max** Type 1 22wh Lithium-Ion Battery: LB20
20v Max** Lithium-Ion Battery Charger: LCS20
Lithium 2 Amp Fast Charger: L2AFC
Lithium 2 Amp Fast Charger: L2AFCBST
20v Max** Lithium-Ion Battery Charger: LCS1620
