11
HL5403, HL5404
www.chpower.com
Replacement Parts List for Pump/Motor
1 M6 Lock washer n l 8
2 M6 X 50 Head bolt l 4
3 Cylinder head l 1
4 Head gasket 6 1
5 Valve plate o 2
6 Metal gasket o 1
7 Valve o 2
8 Valve plate gasket 6 1
9 Cylinder s 1
10 M8 X 25 Cylinder bolt s 2
11 Cylinder gasket 6 1
12 Wrist pin t 1
13 Compression ring t 2
14 Oil ring t 1
15 Wrist pin retainer t 2
16 Piston t 1
17 Connecting rod HL030300AV t 1
18 M6 X 20 Bolt n 5
19 M6 Nut — 1
20 Eccentric — 1
21 Capacitor : 1
22 M8 Lock washer s : 3
23 M8 Nut : 1
24 Crankcase cover n 1
25 O-ring w 1
26 Sight glass w 1
27 O-ring v 1
28 M5 x 10 Drain plug v 1
29 O-ring m 1
30 Breather m 1
31 Crankcase cover gasket 6 1
32 Crankcase — 1
33 M5 Washer — 4
34 M5 X 16 Shroud screw — 4
35 Oil seal — 1
Ref. Part
No. Description No. Qty.
Ref. Part
No. Description No. Qty.
36 Bearing — 1
37 Rotor — 1
38 Bearing — 1
39 Stator — 1
40 Rear end bell — 1
41 Thermal overload — 1
42 Fan u 1
43 Snap ring u 1
44 M5 Plain washer — 4
45 M5 Lock washer — 4
46 M5 x 120 Motor bolt — 4
47 Easy start valve HL036200AV 1
48 Washer l 4
REPLACEMENT PARTS KITS
s Cylinder kit HL031500AV
n Crankcase cover kit HL031800AV
l Cylinder head kit HL031200AV
u Fan kit HL032200AV
t Piston kit HL031600AV
o Valve Plate kit HL031400AV
m Breather kit HL032100AV
w Sight glass kit HL031900AV
v Drain plug kit HL032000AV
6 Gasket kit HL031300AV
: Capacitor kit HL036400AV
— Not available
