HL5403, HL5404
Replacement Parts List for Oil Lubricated Compressor
1 Shroud t 1
2 Air filter (includes element) HL030100AV 1
3 Elbow, brass HL030200AV 1
4 Pump/Motor assembly See next page
for pump/motor
parts list —
5 Bolt — 4
6 Bolt — 4
7 1/4 inch Industrial coupler (M) MP333600AV 2
8 Manifold plate — 1
9 Washer — 4
10 Nut — 4
11 Left side pressure gauge outlet HL036300AV 1
12 Manifold HL035700AV 1
13 Grip N/A 1
14 Control panel tube n 1
15 Elbow HL035800AV n 1
16 Unloader tube s 1
17 Nut with captive ferrule, to
pressure switch s 1
18 Safety valve V-215100AV 1
19 Power cord EC014500AV 1
20 Base — 1
21 Pressure switch (125 psi cut-out /
95 psi cut-in) HL031000AV 1
21a Unloader valve (not shown) CW212400AV 1
22 Check valve HL030500AV 1
23 Plug ST022500AV 1
24 Straight tube fitting HL035900AV n 1
Ref. Part
No. Description No. Qty.
Ref. Part
No. Description No. Qty.
25 Ferrule u 2
26 Nut u 2
27 Exhaust tube u 1
28 M6 x 12 Bolt — 3
29 M6 Washer l 7
30 Drain valve D-1403 1
31 Rubber foot l 4
32 M6 x 16 Bolt l 4
33 Tank assembly — 1
34 Pump motor cord strain relief CW212800AV 1
35 Powercord strain relief CW212300AJ 1
36 Nut, to check valve s 1
37 Ferrule, to check valve s 1
38 Lock washer — 4
39 Mounting screws t 10
40 Washers t 10
41 Right side pressure gauge tank HL036100AV 1
42 Nut — 3
REPLACEMENT PARTS KITS
s Unloader tube kit HL039100AV
n Manifold tube kit HL036000AV
l Foot kit HL032400AV
u Exhaust tube kit HL032300AV
t Shroud kit HL031100AV
— Not available
