SKU 93218 For technical questions, please call 1-800-444-3353. Page 13
OPERATING INSTRUCTIONS
1. WARNING! Always wear safety impact eye goggles and heavy work gloves
when using the Masonry Saw. Using personal safety devices reduce the risk for
injury.
2. Place the Masonry Saw on a flat, level, sturdy surface capable of supporting the
weight of the Saw and all workpieces.
3. Unlock the Table Lock (25) to allow the Table (27) to freely slide forward
and backward. (See Assembly Diagram.)
4. Make sure the Power Switch (20) of the Masonry Saw is in its “OFF” position.
Then, plug the Power Cord Plug (22) into the nearest 120 volt, grounded,
electrical outlet. (See Assembly Diagram.)
5. Pull the Table (27) backward away from the Saw Blade (15). Then, place the
workpiece on the Table and align the cut line on the workpiece with the Saw
Blade. Make sure the workpiece to be cut is pressed firmly against the Table.
(See Assembly Diagram.)
6. Turn the Power Switch (20) of the Masonry Saw to its “ON” position, and allow
the Saw Blade (15) to spin up to full speed. (See Assembly Diagram.)
7. While holding the workpiece firmly with one hand, use the other hand to push the
Table (27) slowly forward to feed the workpiece into the Saw Blade (15). Always
keep hands and fingers a safe distance away from the spinning Saw Blade.
(See Assembly Diagram.)
8. Continue
slowly
feeding the workpiece into the Saw Blade (15) until the cut is
completed. (See Assembly Diagram.)
9. Once the cut is completed, turn the Power Switch (20) to its “OFF” position and
allow the Saw Blade (15) to spin down and stop on its own.
(See Assembly Diagram.)
10. Unplug the Power Cord Plug (22) of the Masonry Saw from its electrical outlet.
Then, remove the cut workpiece and debris from the Table (27). (See Assembly
Diagram.)
11. Lock the Table Lock (25) to secure the Table (27) in place. Then, store the
Masonry Saw in a clean, dry, safe location out of reach of children and other
unauthorized people. (See Assembly Diagram.)
