SKU 93218 For technical questions, please call 1-800-444-3353. Page 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the
front cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
Item Description
Electrical Requirements
(Saw)
120 Volt AC / 60 Hz / 9.2 No Load AMPs / 1.5 HP
/ 5200 RPM
Power Switch Type: 2 Push Buttons (ON & OFF)
Power Cord: 76” Long / 16AWG x 2C
Power Cord Plug Type: 2 Prong Polarized
Blade Size/Type 10” Diameter / Diamond (Included)
Blade Arbor Diameter 7/8”
Cutting Length 12”
Cutting Depth 3.5”
Table Travel 16-1/4”
Overall Dimensions 28” L x 14-1/2” W x 14 H
Unit Weight 28 Pounds
