Appendix A Repackaging the Router
Repackaging the Routers
A-2
Cisco XR 12416 Router Chassis Installation Guide
OL-xxxxx-xx
This section contains the following information and procedures:
• The Router Shipping Package, page A-2
• Tools and Equipment, page A-6
• Safety Recommendations, page A-6
• Removing the Router from the Rack, page A-7
• Installing the Router on the Shipping Pallet, page A-16
• Completing the Repackaging, page A-23
Note You must use the original shipping package supplied by Cisco when repackaging
the router. If you do not have the original system package, contact your
Cisco service representative for assistance.
The Router Shipping Package
Figure A-1 shows the router in an exploded view of the parts making up the
shipping package components.
Because of the weight and height of the router, the router shipping pallet
incorporates a scissor-jack platform. This scissor-jack platform enables a team of
two installers to remove a fully-loaded router from the pallet and insert it into an
equipment rack, or extract a fully loaded router from a rack, without removing any
of the components from the router chassis.
The router should be bagged to protect it against dust and electrostatic discharge
(ESD) and secured to the scissor-jack platform by four anchor clips. The anchor
clips are inserted into slots along the bottom edges of the router chassis side
panels and secured to the scissor-jack platform by four bolts. In turn, the
scissor-jack platform is secured to the shipping pallet by eight hold-down brackets
that are bolted to the top of the shipping pallet.
The shipping pallet consists of a U-shaped wood and foam pallet body and a wood
and foam pallet front bar. The pallet front bar fastens to the open end of the pallet
body to create the fourth bearing surface for the scissor-jack platform and to
complete the base needed to support the walls of the shipping container.
