P-MU-DG600 Ver. B Publish:2004.08.27 Page: 2/ 6
II. Specifications:
Operating Voltage
DC +8.5V to 16V
Current Draw
Average 50mA, Peak 100mA @ 12Vdc
Transmitting Frequency
125 KHz
Memory Volume
600 Proximity cards/tokens and PIN codes
Read Range
Up to 10 cm (Depending on local installation conditions)
Keyboard
12 digits keypad (0~9, *, #)
Input
Request-to-exit, door reed switch, auxiliary reader
Relay Electric Current
2A MAX @30Vdc ；0.4A @ 120Vac
Invalid PIN Lock-out
The system will shut down for 60 seconds while 5 times of
incorrectly Master Codes enrolled or PIN codes attempted
（None beeper signal of keypad activations）.
Relocking timer
Strike Time: 1~99 seconds (adjustable)
Strike mode: Access Timer or Latch
Alarm Function
Door Held Open Alarm: 10~990
Door Forced Alarm
Panel Temper Alarm
DG-600E: Wiegand 44 or 26-bit only format (adjustable),
hexadecimal (Em 64-bit standard R/O or compatible)
Format
DG-600H: Wiegand 26~37 or 26-bit only format (adjustable),
hexadecimal (125KHz 26~37-bit R/O or compatible)
Case Material
ABS (UL94V0)
Color
Dark gray/ Beige White
Operating Temperature
-20~+70
℃
Ambient Humidity
5~95% relative humidity non-condensing
Visual Signals
3 LED display with audible indication (Red/Yellow/Green)
EMC
Meet CE requirement
