Page 17For technical questions, please call 1-800-444-3353.SKU 44506
When ordering a part from this drawing,
add an “A” prex to the part number.
Parts List and Diagram A - Pulley and Spindle
Part Description
A1 Bushing, Rubber
A2 Knob
A3 Screw, Pan Hd., M5x0.8-12
A4 Belt, V5, 5/16x26
A5 Guard with Labels
A6 Screw-washer Hd., M6x10-16
A7 Ring, Retaining
A8 Bearing, Ball, 17 mm
A9 Spacer
A10 Insert, Pulley
A11 Pulley, Spindle
A12 Nut, Pulley
A13 Clamp, Cord
A14 Screw, Pan Hd., M5x0.8-16
A15 Washer, Foam
