Page 18 For technical questions, please call 1-800-444-3353. SKU 44506
When ordering a part from this drawing,
add a “B” prex to the part number.
Parts List and Diagram B - Chuck and Spindle Shaft
Part Description
B1 Gasket, Quill
B2 Bearing, Ball, 12 mm
B3 Tube, Quill
B4 Screw, Pan, M5x0.8-20
B5 Collar, Stop
B6 Ring, Retaining
B7 Shaft, Spindle
B8 Chuck
B9 Chuck Key
B10 Nut, Hex, M6x1.0
B11 Nut, Hex, M5x0.8
B12 Stop, Rod
