Page 12SKU 44914
Parts List
Item # Description
1Rear Cover
2 Middle Cover
3 Carbon Brush Holder
4 Carbon Brush
5 Brush Holder Cap
6Switch
7 Switch Socket
8 Brush Holder Spring
10 Stator
13 Pan Hd. Screw
15 Pan Hd. Screw
16 Strain Relief
17 Tapping Screw
18 Ball Bearing
19 Armature Assembly
20 Fan
21 Ball Bearing
26 Power Cord with Plug
27 Wave Washer
28 Cord Guard
29 Motor Housing
30 Collet Cones
31 Collet Nut
32 Base
33 Gear
34 Screw
Item # Description
37 Base Plate
38 Chip Fence
39 Thumbscrew
40 Wave Washer
41 Flat Washer
42
Trimmer Guide Assembly:
(420~430, 39, 40, 41)
420 Link
421 Counter Sunk Hd. Screw
423 Set Plate
424 Adjusting Set Screw
425 Screw
426 Guide Wheel
427 Guide Block
428 Flat Washer
429 Wave Washer
430 Thumbscrew
44
Straight Guide Assembly:
(440~445, 39, 40, 41)
440 Set Screw
441 Adjusting Plate
442 Straight Guide
443 Flat Washer
444 Wave Washer
445 Thumb Nut
46 Pan Hd. Screw
48 Flat Washer
49 Knob Set
101 Spanner
102 Spanner
NOTE: Some parts are listed and shown for illustration purposes only and are not available indi-
vidually as replacement parts.
REV 08/01
