Page 8SKU 44914
Unpacking
When unpacking, check to make sure the following parts are included. If any parts are
missing or broken, please call Harbor Freight Tools at the number on the cover of this
manual as soon as possible.
Operation
Caution: Before Trimming, run the tool for about 10 seconds to ensure that all moving parts
are running smoothly, and there are no loose parts, rattles, or sparking that would indicate
damage. Be sure the bit is firmly and properly installed before use. Improperly installed bits
may eject suddenly at high speed from the Trimmer, resulting in personal injury.
Installing the Router Bit
1. Unplug the Trimmer Router from the electrical outlet.
2. Insert the small Spanner (101) wrench over the spindle to keep it from turning.
3. Using the large Spanner (102) wrench, loosen the Collet Nut (31), but do not remove.
4. If there is already a bit in the Collet Cone, remove it.
5. Push the shank end of the new bit through the opening in the Collet Nut. There may be
some resistance, so make sure that it goes in all the way.
6. While holding the small Spanner (101) over the spindle, tighten the Collet Nut with the
large Spanner (102).
Spanner (101)
Spanner (102)
Straight Guide Assy
(44)
Carbon Brushes (4)
Straight Guide Assy (44)
Trimmer Router
Trimmer Guide Assy (42)
Rev 08/01; 03/07
