SKU 67026 For technical questions, please call 1-800-444-3353. Page 11
b.
Rip Fence to adjust. Tighten both
Fence Bolts before use.
Remove Rip Fence when not in use.c.
DEPTH ADJUSTMENT:4.
1
1
–
2
1”
Depth
Knob
Depth
Mark
(measured
from top
of tab)
Depth
Scale
Base Plate
a. To read the approximate blade
depth (at 0° bevel):
Compare the Depth Mark (measured
from the top of the tab) to the Depth
Scale - the illustration above shows
about 1”.
To adjust the depth: b.
the Base Plate to the desired depth.
Tighten the Depth Knob before
use.
Work Piece and Work Area Set Up
Work piece selection:1.
Work piece must be free of foreign a.
objects and loose knots.
Do not use to cut logs, tree limbs, or b.
uneven lumber.
Wet lumber, green (unseasoned) c.
lumber, and pressure treated lum-
ber all have an increased potential
for kickback and should only be cut
with a blade designed for cutting that
lumber. Wear a NIOSH-approved
respirator and have appropriate ven-
tilation whenever cutting pressure
treated lumber.
Designate a work area that is clean 2.
and well-lit. The work area must not
allow access by children or pets to
prevent distraction and injury.
Secure loose workpieces using a vise 3.
or clamps (not included) to prevent
movement while working.
Verify that there are no utility lines or 4.
hardware in or near the workpiece.
This is especially critical for plunge
cuts.
Charging Instructions
The Charger (SKU 67031) and Bat-1.
tery Pack (SKU 67029) are sold
separately. Please refer to the 67031
Charger manual for important safety
warnings and proper instructions on
charging the battery pack.
WARNING! Do NOT use a different 2.
Charger or Battery Pack to power
this tool.
