SKU 93351 For technical questions, please call 1-800-444-3353. Page 17
PARTS LIST
NOTE: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description Qty.
1 Hex Bolt 4
1A Spring Washer 4
1B Flat Washer 4
2 Cylinder Head 1
3 Head Washer 1
4 Valve Seat 1
5 Column Pin 2
6 Inlet Valve Plate 1
7 Upper Gasket 1
8 Cylinder 1
9 Lower Gasket 1
10A Piston Air Ring 2
10B Piston Oil Ring 1
11 Retaining Ring 2
12 Piston 1
13 Piston Pin 1
14 Connect Rod 1
15 Crankcase 1
16 Crankshaft 1
17 In-Six Angle Bolt 1
18 Rubber Washer 4
19 O-Ring 1
20 Flange Head Bolt 1
21 Starting Capacitor 1
22 Running Capacitor 1
23 Hex Nut 2
24 Saw Washer 2
25 Flat Washer 2
26 Terminal Connector 2
27 Nylon Belt 2
29 Pan Head Screw 2
30 Protection Plate 1
31 Circuit Breaker 1
34 Shaft Oil Seal 1
35 Ball Bearing 1
36A Motor Stator Assy. 1
Part Description Qty.
36B Motor Rotor Assy. 1
37 Bearing 1
38 Wave Washer 1
39 Motor Back Cover 1
40 Pan Head Screw 1
41A Starter Switch Sheet 1
41B Starter Switch 1
41C Pan Head Screw/Nut 1 ea.
42 Pan Head Screw 2
43 Washer 2
44 Starter Switch Cover 1
45 Pan Head Screw 4
45A Plastic Washer 4
46 Motor Fan 1
46A Pan Head Screw 1
46B Hex Nut 1
46C Flat Washer 2
47 Retaining Ring 2
48 Flange Head Bolt 4
48A Flat Washer 4
48B Spring Washer 4
49 Hex Bolt 4
49A Flat Washer 4
50 Tank 1
50A Tank Handle 1
50B Lock Knob 2
51 Flat Washer 4
51A Spring Washer 4
52 Hex Nut 4
53 Tank Wheel 2
53A Axle 2
54 Retaining Ring 2
55 Exhaust Elbow 1
56 Exhaust Tube 1
57 Check Valve 1
58 Discharge Tube 1
Part Description Qty.
59 Drain Valve 1
60 Hex Bolt 2
60A Flat Washer 2
61 Rubber Foot 2
62 Special Washer 2
63 Hex Nut 2
64 Power Cord 1
65 Tank Pressure Gauge 1
66 Pressure Switch Box 1
67 Safety Valve 1
68 Connector 2
69 Air Outlet Valve 1
70 Pressure Regulator 1
71 Tool Pressure Gauge 1
72 Oil Sight Glass 1
73 O-Ring 1
74 Cap Screw 6
75 Spring Washer 6
76 Front Housing Cover 1
77 Seal 1
78 Oil Breather Cap 1
80 Protection Plate 2
81 Cap Screw 4
82 Motor Cover 1
83 Pan Head Screw 2
84 Pan Head Screw 2
85 Air Filter 1
86 ON/OFF Knob 1
87 Wrench 1
88 Round Key 1
89 Flat Washer 1
90 Hex Nut 2
91 Washer 1
92 Radiator 1
93 Hex Bolt 2
REV 05/06
