SKU 93351 For technical questions, please call 1-800-444-3353. Page 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep bystanders, children, and visitors away while operating a power tool
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
1.
2.
3.
Electrical Requirements 120V / 60 Hz / Single Phase / 13.5 Amps (With Load)
2.5 HP / Single Phase / 3450 RPM
3-Wire Power Cord (6’ Long x 16 Gauge x 3 Cords)
3-Prong Power Cord Plug
Air Tank Capacity 29 Gallons
Pump Stage Single Stage (Direct Drive)
Pump Style Single Cylinder Pump
Maximum Air Pressure 110 PSI w/Automatic Shut Off
Auto Start PSI Starts at 85 PSI
Regulators w/Gauges Reads 0-200 PSI (in 10 PSI Increments)
Air Flow Capacity 8.5 CFM @ 40 PSI / 7.5 CFM @ 90 PSI
Air Outlet Size ¼”-18 NPT
Accessories Air Filter (Qty. 1)
Tool Weight 154 Pounds
