PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance
and cleaning procedures, parts list and assembly diagram. Keep your invoice with this manual. Write the
invoice number on the inside of the front cover. Keep this manual and invoice in a safe and dry place for future
reference.
SAFETY WARNINGS AND PRECAUTIONS
WARNING: When using tool, basic safety precautions should always
be followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Do not expose to rain. Keep work area well lit. Do not use
electrically powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not
let them handle machines, tools, extension cords, or air hoses.
4. Store idle equipment. When not in use, tools must be stored in a dry location
to inhibit rust. Always lock up tools and keep out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small tool or attachment
to do the work of a larger industrial tool. There are certain applications for
which this tool was designed. It will do the job better and more safely at the rate
for which it was intended. Do not modify this tool, and do not use this tool for a
purpose for which it was not intended.
SKU 93760 For technical questions, please call 1-800-444-3353 PAGE 2
Item Description
Nail Capacity 2-3/16” to 3-9/16” Long x 8 to 10 Gauge / Paper, Plastic, and Wire Collated
Magazine Capacity Up to 90 Nails Per Load
Magazine Angle 28°
Operating PSI 125 PSI Maximum *
Required CFM 12 CFM @ 90 PSI
Air Inlet Size 1/4”-18 NPT
Air Inlet Screen 20 Mesh
Included
Accessories
Goggles (Qty. 1) / Tool Oil (Qty. 1) / Hex Wrenches (Qty. 4)
Carrying Case (Qty. 1)
Included Nails 0.113” Diameter x 2-1/2” Long, Paper Collated, Clip Head Nails (Qty.100)
0.131” Diameter x 3” Long, Wire Collated, Full Head Nails (Qty.102)
Additional Features Full Sequential Firing Safety Mechanism / 360° Adjustable Exhaust
Net Weight 8.5 Pounds
* The air pressure setting must not exceed job site regulations/restrictions. The air pressure setting
must not exceed 90 PSI when being used with work pieces that have a thickness of less than 1-3/4”.
REV 11/06, 01/07
