SKU 94355 For technical questions, please call 1-800-444-3353 PAGE 13
7. Always store the Air Compressor in a clean, dry, safe location out of reach of
children and other unauthorized people.
8. CAUTION! All maintenance, service, or repairs not mentioned in this
manual must only be performed by a qualified service technician.
6. To replace the Fuse: An indicator of a blown Fuse (28) is if its wire strand within
is burnt in half. When replacing the Fuse, make sure to install a new 15 AMP
Buss Fuse.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER
AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
4. To clean, wipe with a damp cloth, using a mild detergent. Never use solvents
such as thinner, alcohol, trichloroethylene, etc. to clean the Air Compressor.
5. To replace the Motor Carbon Brushes: It may become necessary at sometime
to replace or clean the two Carbon Brushes (68) when the Motor performance
decreases, or stops working completely. The Carbon Brushes are located on
each side of the Motor Cover (46). To replace the Carbon Brushes, remove
the two Brush Holder Covers. Remove the Brush Caps. Then, remove the two
the two Carbon Brushes from the two Brush Holders. If the Carbon Brushes are
worn down more than 1/2, replace
both
Carbon Brushes. If, however, the Carbon
Brushes are just dirty they may be cleaned by rubbing them with a pencil eraser.
When installing the Carbon Brushes, make sure the carbon portion of the Carbon
Brushes contact the Motor’s Rotor and that the springs face away from the Motor.
Also, make sure the springs operate freely. After replacement or cleaning, replace
the two Brush Holder Covers. NOTE: New Carbon Brushes tend to arc or spark
when first used until they wear and conform to the Motor’s Rotor. (See Assy.
Diagram.)
