SKU 94355 For technical questions, please call 1-800-444-3353 PAGE 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES AND PRECAUTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
Electrical Requirements 120 V / 60 Hz / 13 Amp / 2 HP Rated, 3 HP Peak
Power Cord Type: 16 Gauge x 3 C x 6’ Long
Power Plug Type: 3-Prong, Grounded
Fuse Size: 15 AMP Buss Fuse
Switch Type: Rotary On/Off Switch
Operating Air Pressure Pressure On: 85 PSI / Pressure Off: 125 PSI
Air Flow 6.0 CFM @ 40 PSI / 4 CFM @ 90 PSI
Air Tank Capacity 8 Gallons
Outlet Thread 1/4" – 18 NPT
Pressure Gauge Measures 0 ~ 230 PSI in 20 PSI Increments / 0 ~ 16 KG/CM² in 2 BAR Increments
Additional Features Thermal Overload Protection / Steel Tube Handle
Rubber Wheels / Brass Valve Tank Drain / Single Cylinder Pump
Unit Weight 51 Pounds
235309
SAFE OPERATION
1. RISK OF FIRE OR EXPLOSION:
Do not spray flammable liquid in a confined area or towards a hot surface.
Spray area must be well ventilated.
Do not smoke while spraying or spray where spark or flame is present.
REV 11/06
