UNPACKING
Your Air Drill comes completely assembled. Included is a chuck key for use with this tool.
Check to make sure everything is included. If any parts are missing or broken, please call
Harbor Freight Tools at the number on the cover of this manual.
ASSEMBLY
Your Air Drill is completely assembled. Follow the steps below to install drill bits and prepare for
the operation of your Air Drill.
Drill Bit Installation
Step 1: Select the drill bit needed for the drilling you wish to perform.
Step 2: Open up the Jaws of the Drill by turning the DRILL CHUCK (#2) as shown in Figure 1.
Motor Housing
(#17)
Drill Chuck
(#2)
Figure 1 — Opening the Jaws
Step 3: When the Jaws are open wide enough to insert the drill bit, slide the bit into the DRILL
CHUCK as far as possible.
(#16)
