SKU 94585 For technical questions please call 1-800-444-3353. Page 8
Using The Air Drill
Step 1: Mark the material you wish to drill at the spot for the hole. Make sure your drill bit is
the correct size for the hole you need to make.
Step 2: Clamp the material in a vise to make sure the material does not move or begin to spin
while drilling.
Step 3: Wear eye protection to guard against flying wood or metal.
Step 4: Set the compressor’s pressure regulator to 90 PSI. Do not set the compressor’s outlet
regulator over 90 PSI.
Step 5: Connect the Air Drill to the air compressor’s hose. If leaking is detected, disconnect
the air hose and repair before use.
Step 6: Grip the Air Drill firmly. Place the drill bit on the spot
marked in Step 1.
Step 7: To begin drilling, press the TRIGGER (#18).
Step 8: Your Air Drill has a variable speed for drilling. To vary the speed of the drilling action,
vary the pressure on the TRIGGER.
Step 9: Drill only as deep as necessary. Do not drill deeper than necessary into walls or other
areas where you cannot identify any possible hazards behind the drilling surface.
Step 10: When you have drilled the hole, remove the drill bit from the hole while the Air Drill is still
spinning. This is to prevent the drill getting caught in the hole and causing damage.
Step 11: If the drill bit does get caught while you are drilling,
immediately release the TRIGGER.
CAUTION
Do not operate the Air Drill
before placing the drill bit
on the material.
WARNING
Do not touch the DRILL
CHUCK or the drill bit while
the Air Drill is spinning.
