Page 8
SKU 97526
For technical questions, please call 1-800-444-3353.
Part Description Q’ty
1 Hex Bolt 1
2 Deector 1
3 Seal 1
4 Spring 1
5 Head cap 1
6 O-RIng 1
7 O-RIng 1
8 Head Valve Piston 1
9 O-Ring 1
10 O-Ring 1
11 Piston-Driver Unit 1
12 Lining Ring 1
13 O-Ring 1
14 Cylinder 1
15 Bumper 1
16 O-Ring 1
17 Body 1
18 Nozzle 1
19 Seal 1
20 Trigger Valve Head 1
21 Trigger Plunger 1
22 O-RIng 1
23 O-Ring 1
24 Trigger Valve Guide 1
25 Spring 1
26 E-Ring 1
27 Trigger 1
28 Retainer Pin 1
29 Hex Bolt 1
30 Washer 1
31 Pusher Unit 1
Part Description Q’ty
32 Spring Holder 1
33 Spring 1
34 Side Cover 1
35 Rear Plate 1
36 Hex Bolt 1
37 Hex Bolt 1
38 Hex Bolt 1
39 Spacer 1
40 Bracket 1
41 Hex Bolt 1
42 Driver Guide 1
43 Hex Bolt 1
44 Hex Bolt 1
45 Adjust Dial 1
46 Limiting Plate 1
47 Upper Right Magazine 1
48 Hex Bolt 1
49 Guide Piece 1
50 Pusher Plate 1
51 Upper Left Magazine 1
52 Pin 1
53 Limiting Plate 1
54 Hex Bolt 1
55 Hex Bolt 1
56 Tail Hanger 1
57 Lock Nut 1
58 Spring 1
59 Click Lever 1
60 Trigger Lock/Safety 1
61 Air Coupler 1/4”-18 NPT 1
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS
LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL
ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR
SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR
SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL
RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR
HER INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
