PART # DESCRIPTION
1 HOLD DOWN BRACKET
2 FACE PLATE
3 SIDE HAND-HOLD (RIGHT)
4 SIDE HAND-HOLD (LEFT)
5 SLIDING TABLE
6 SLIDING TABLE SUPPORT
7 LOCKING KNOB BRACKETS
8 SLIDING RAIL
9 BASE PLATE
10 MITER BAR
11 LOCK KNOBS
12 TOGGLE CLAMP
13 ANGLE BRACKET
14 10 - 32
x
3
⁄8" BUTTON HD SCREWS
15
1
⁄4" - 20 x 1
3
⁄4" THUMB SCREWS
16
1
⁄4" - 20 WING NUTS
17
1
⁄4" - 20 x 1" CAP SCRW
18
1
⁄4" - 20 x
1
⁄2" CAP SCRW
19
1
⁄4" - 20 x
1
⁄2" BALL PLUNGER
20
1
⁄2" x
1
⁄4" x
5
⁄8" ALUMINUM BUSHING
21 PLUNGER
22
5
⁄16" - 18 HEX NUT
23
1
⁄2" TEFLON TAPE
24
1
⁄8" ALLEN
®
WRENCH
25
3
⁄16" ALLEN
®
WRENCH
26 BUTTON HEAD SCREW
SECTION IX: PART LIST
