62 Freedom SW 3000 Owner’s Guide
Specifications
Without a battery temperature
sensor
Three settings with the following
temperature values:
Cool 50 °F (10 °C)
Warm 77 °F (25 °C)
Hot 104 °F (40 °C)
The default value for this setting is
Hot, and it can only be changed by a
dealer, factory, or service centre.
With a battery temperature
sensor
The temperature compensation
coefficients on a 12 volt battery are as
follows:
Flooded: 27 mV × (25 °C – BTS °C)
Gel: 27 mV × (25 °C – BTS °C)
AGM: 21 mV × (25 °C – BTS °C)
Equalization cycle Yes, manual via SCP
Number of independent battery
banks
1
Battery bank size settings 50 – 2000 Ahr
Battery type settings Flooded, AGM, Gel, Custom
Power factor corrected
charging
Yes
Input power factor at full
charge rate
> 0.95
Charger Specifications
AC input voltage 85 – 135 VAC
AC input frequency 60 Hz nominal, 55 – 65 Hz operating
range
Minimum battery voltage 5.0 VDC
Maximum DC output voltage 16.0 VDC
Peak charger efficiency 84%
Maximum charge current 150 A
Maximum charge current 150 A
Charger Specifications
