11-28
Cisco 12000/10700 v3.1.1 Router Manager User Guide
OL-4455-01
Chapter 11 Layer 3 QoS
WRED Tx Configuration
WRED Tx Configuration
The WRED Tx Configuration section covers the following areas:
• Applying a CoS Queue Group to an Interface
• Removing a CoS Queue Group from an Interface
• Changing the Association of a CoS Queue Group
• WRED Tx Configuration Window—Detailed Description
Applying a CoS Queue Group to an Interface
To apply a CoS Queue Group to an interface, proceed as follows:
Step 1 Choose Cisco 12000/10720 Manager>Configuration>Interface>QoS>WRED Tx Configuration
from a relevant object icon (in the Map Viewer window or from an object pick list) to launch the WRED
Tx Configuration window. See Table 11-1 on page 11-2 for information on which objects allow you to
launch the WRED Tx Configuration window (see Figure 11-13 on page 11-29).
