 )>>;">D=C8=6%03B – The four corners of the
saw provide areas to clamp, bolt or nail the saw
to a flat work surface.
 (;838=60B4GC4=B8>=B – These extensions
provide extra workpiece support and are espe-
cially useful when cutting long workpieces.
 0B4GC4=B8>=;0<?8=6!4E4AB – These
levers lock the base extensions at the desired
positions.
 !4=6C7(C>?">34;>=;H – For repetitive
cuts of the same length. Can be moved to left
side, if desired.
 DBC%>AC – The dust port can accommodate
the dust chute and dust bag or a 1-1/4" vacuum
hose hookup.
 4E4;!>2:!4E4A – The front-positioned bevel
lock lever locks the head assembly at the de-
sired bevel angle.
 4E4;'0=64(4;42C>A =>1 – Allows selection
of the bevel range, 0° to 45° left, 0° to 45° right,
and complete range of 47° left to 47° right.
 (;834'08;!>2: =>1 – The slide rail lock knob
locks the slide rails when you are not making
slide cuts and when you are transporting the saw.
 (;834'08;B – Guide the head assembly when
making slide cuts.
 ;0<? %>B8C8>= >;4B There are two (2)
holes (not shown) behind the fence for placing
the clamp.
 &D82:2C8>=;0<?">34;>=;H Pro-
vides fast clamping of workpiece.
 ,>A:?8424;0<?">34;>=;H – Pro-
vides fast clamping of workpiece.
 >A3,A0? – Allows you to easily wrap up the
cord so it’s out of the way when transporting or
storing.

