Page 11For technical questions, please call 1-800-444-3353.SKU 93632
General Operating Instructions
Note: The motor will heat up as it is used. To
avoid motor burn out, do not use continu-
ally for more than 20 minutes at a time.
Allow the tool to cool down for at least 10
minutes before resuming work.
The Trigger (46) has a variable speed 1.
feature. Simply turn the dial below the
Trigger to adjust the drill speed. The
dotted lines on the dial are spaced from
narrow to wide to indicate increasing drill
speed.
The trigger lock button on the side of the 2.
handle, when activated, will allow the drill
on the trigger. To release the trigger
-
ger and release it.
The Direction Switch is located behind 3.
the Trigger (46). When button is pushed
in on the left side of housing, the drill will
rotate counterclockwise. When button
is pushed in on the right side of housing,
the drill will rotate clockwise (forward).
Note: Most drill bits are designed to work
while turning clockwise. Before drilling,
correct direction.
CAUTION! Do not change direction while
the drill is operating.
Place the drill tip on the work piece, and 4.
start the tool.
Apply light pressure on the tool to help it 5.
drill into the workpiece.
When the hole has been drilled, remove 6.
the bit from the hole, release the Trigger
and trigger lock.
Unplug the tool and store it in a safe 7.
place.
