Page 14 For technical questions, please call 1-800-444-3353. SKU 93632
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
Part Description Qty.
1 Spring Washer m5 4
2 Screw ST5x550 4
3 Chuck Key 1
4 Cap Head Screw m6x22 1
5 Chuck 1
6 Washer m21 1
7 Gear Housing 1
8 Pin m3 2
9 Ball Bearing 6002RS 1
10 Circlip 1
11 Key m3x3.7x10 3
12 Spindle 1
13 Output Gear 1
14 Screw m10x40 1
15 Side Handle 1
16 Circlip m12 1
17 Needle Bearing HK101412 1
18 Second Shaft 1
19 Second Gear 1
20 Circlip m12 1
21 Needle Bearing HK081210 4
22 Gear Housing Cover 1
23 Circlip m10 1
24 Bearing Retainer 1
25 Armature 1
26 Ball Bearing 608.27 1
27 Bearing Bushing 1
28 Winding Guide 1
Part Description Qty.
29 Stator 1
30 Spade Handle Knob 1
31 Spade Handle 1
32 Back Case 1
33 Brush Cap 2
34 Carbon Brush 2
35 Brush Holder 2
36 Hex Nut m8 1
37 Cover for Nut 1
38 Screw ST4x16F 4
39 Housing 1
40 Rubber Sleeve 1
41 Cord and Plug 1
42 Cord Clip 1
43 Screw ST4x16 2
44 Handle Cover 1
45 Screw ST4x18F 2
46 Trigger 1
47  1
48 Screw ST4x550 2
49  1
50 Ball Bearing 6000.2Z 1
51 O-Ring 1
52 Seal Ring 1
53 First Gear 1
54 First Shaft 1
55 Gasket 1
PLEASE READ THE FOLLOWING CAREFULLY


MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY








PARTS LIST
