10
FASTENING STAND TO SUPPORTING SURFACE
If there is any tendency for the scroll saw to move during operation, the scroll saw stand must be
fastened to the floor.
Fig. 17
OPERATING CONTROLS AND ADJUSTMENTS
ON-OFF POWER SWITCH
The on-off switch (A) Fig. 16, is located on the top of the arm, as shown. To turn the saw “ON” push
down on the “ON” portion of the switch and to turn the saw “OFF” push down on the “OFF” por-
tion of the switch.
VARIABLE SPEED CONTROL
Your scroll saw can be operated at speeds of 300 to 2000 cutting strokes per minute by rotating
control knob (B) Fig. 16. With the control knob (B) rotated all the way toward the front of the
machine the speed will be 300 cutting strokes per minute and with the control knob (B) rotated all
the way to the rear, the speed will be 2000 cutting strokes per minute. A series of numbers are pro-
vided on the control knob, as shown, and a witness line (C) is provided on the arm to be used for
reference.
Fig. 16
LOCKING ON-OFF SWITCH
IN “OFF” POSITION
IMPORTANT: We suggest that when the scroll
saw is not in use, the on-off switch be locked in
the “OFF” position using a padlock (A), as
shown in Fig. 17. Available as an accessory
from Delta is the 50-325 padlock, shown at (A).
A
C
B
A
