34 308-125
Parts
– Complete Sprayer
COMPLETE
SPRA
YER
Model 231–148
Includes items 101 to 104
Ref
No. Part No. Description Qty
Ref
No. Part No. Description Qty
101 224–439
HOSE, coupled 3/4 npt(m) x
3/4 nspm(f) swivel, 3/4” ID,
50 ft (15 m) long
1
102 224–472 MASTIC FLOW VALVE
See manual 308–124 for parts
1
103 224–440
HOSE, coupled 3/4 npt x 1/2 npt (mbe),
5/8” ID, 40 ft. (12 m) long
1
104 224–483 BASIC SPRAYER
Includes items 104a – 104c
1
104a 224–442 . 55 GALLON SUCTION KIT
See parts on page 35
1
104b 224–528 . ROOFING PUMP and
PRESSURE CONTROL KIT
See parts on page 35
1
104c 224–482 . SPRAYER DRIVE ASSEMBLY
See parts on page 36
1
104a
See parts on page
35.
104b
See
parts on page 32 and 35.
104c
See parts on page
36.
102
103
101
See manual 308–124
0395A
