SKU 42827 For technical questions, please call 1-800-444-3353. Page 14
GEARED HEAD DRILL MILL MACHINE, HEAD PARTS LIST
Please refer to Parts Diagrams on Page 16 and 17
Part Description Qty.
1-01 Arbor Bolt Cover 1
1-02 Arbor Bolt 1
1-04 C-Retainer Ring 1
1-05 Ball Bearing (80108) 2
1-06 Spindle Sleeve Cover 1
1-07 Oil Seal 1
1-08 Seal Retainer 1
1-09 Cap 1
1-10 C-Retainer Ring 1
1-11 Head Body 1
1-12 Rubber Flange 2
1-13 Feed Base 1
1-14 Lock Nuts 2
1-15 Taper Roller Bearing (7206E) 1
1-16 Rack Sleeve 1
1-17 Spindle Shaft 1
1-18 Taper Roller Bearing (7207E) 1
1-19 Bearing Cap 1
1-20 Gear Shaft 1
1-21 Gear 1
1-22 Grip 4
1-23 Ring 1
1-24 Handle Rod 1
1-25 Fixed Tight Collar 1
1-26 Fixed Tight Collar (thread) 1
1-27 Screw Key 1
1-28 Oil Seal 1
1-29 Gear 1
1-30 Spring and Ball 3
1-31 Gear Shaft 1
1-32 Key 1
1-33 Ring 1
1-34 Gear 1
1-35 Bearing Spacer 1
1-36 Sleeve 1
1-37 Gear 1
1-38 Key 1
1-39 Handle Rod 1
1-40 Knob 3
1-41 Ball Bearing (80202) 3
1-42 Inner Ring 1
1-43 Shaft 1
1-44 Micro Adjusting Indicator 1
1-45 Worm Cover 1
Part Description Qty.
1-46 Ball Bearing (202G) 2
1-47 Worm Shaft 1
1-48 Key 2
1-49 Gear 1
1-50 Oil Seal 1
1-51 Ball Bearing (80107) 1
1-52 Head Body Fix Bolt 2
1-53 Oil Drain Plug 1
1-54 Graduated Rod 1
1-56 Switch Box 1
1-57 Main Cable 1
1-58 Head Handle 1
1-59 Worm Shaft 1
1-60 Worm 1
1-61 Shaft 1
1-62 Handwheel 1
1-63 Nuts 3
1-64 Spring Washer 3
1-65 Bolt 3
1-66 Lever Bracket 2
1-67 Lever (Left) 1
1-68 Lever (Right) 1
1-69 Screw 2
1-70 Lever Shaft (Right) 1
1-71 Lever Shaft (Left) 1
1-72 Name Plate 1
1-73 Screw 4
1-74 Screw 4
1-75 Speed Lever 2
1-76 Degree-Meter 1
1-77 Rivet 2
1-79 Head Collar 1
1-80 Motor Cable 1
1-81 Oil Filler Plug 2
1-82 Bolt 6
1-83 Pin 2
1-84 Head Body Cover 1
1-85 Screw with Plumb Knob 1
1-86 Motor 1
1-87 Fluid Level Indicator 1
1-89 Airow Plug 1
1-90 C-Ring 2
1-91 Set Distance Nut 1
1-92 Set Position Block 1
