SKU 42827 For technical questions, please call 1-800-444-3353. Page 15
DRILL MILL MACHINE, PARTS LIST
Please refer to Parts Diagrams on Page 16 and 17
REV 09b
Part Description Qty.
1-93 Lock Nut 1
1-94 Support Base 1
1-95 Handle 1
1-96 Oil Seal 2
1-101 Head Raise Bracket 1
1-102 Limit Plate 4
1-103 Spring Cover 1
1-104 Spring 1
1-105 Spring Base 1
1-106 Pinion Shaft 1
1-107 Worm Gear 1
1-108 Feed Cover 1
1-110 Spring Base 1
1-111 Lock Bolt with Knob 1
1-115 Spring 1
1-134 Hex Head Bolt 1
1-135 Hex Nut 1
1-136 Spring Pin 1
1-137 Lock Washer 1
1-139 Phillips recessed round head screw 3
1-140 Travel Switch 2
1-141 Hex Nut 1
1-142 Key 1
1-143 Hex Socket Head Screw 2
1-145 Hex Set Screw 3
1-146 Hex Set Screw 1
1-147 Hex Set Screw 2
1-148 C-Retainer Ring 1
1-150 Locknut 2
1-151 Washer 2
1-153 Hex Set Screw 1
1-154 C-Retainer Ring 2
1-155 Hex Set Screw 4
1-156 Rod 1
1-157 Retainer 1
1-158 Knob 1
1-184 Screw 1
1-185 Washer 1
1-187 Washer 1
1-188 Phillips Head Recessed Screw 1
1-189 Travel Switch Base A 1
1-190 Travel Switch Base B 1
2-01 Table Handle with Wheel 3
2-02 Dial Clutch 2
Part Description Qty.
2-03 Thrust Bearing (8103) 4
2-04 Square Flange 1
2-05 Table Screw 1
2-06 Base 1
2-07 Gib Strip 1
2-08 Column Base 1
2-09 Column Base Ring 1
2-10 Rack 1
2-11 Column Head 1
2-12 Gib Strip Bolt 2
2-13 Leaf Screw 2
2-13-2 Knob 2
2-14 Moveable Fixed Bock 2
2-15 Table Base Nut 1
2-16 Center Base 1
2-17 Antidust Plate 1
2-18 Antidust Plate 1
2-19 Antidust Plate 1
2-20 Table Clutch 1
2-22 Left Flange 1
2-23 Table Nut 1
2-24 Table Screw 1
2-26 Right Flange 1
2-27 Gib Strip 1
2-28 Table 1
2-29 Fixed Block 2
2-30 Moveable Fixed Ring 2
2-37 Base Screw Collar 1
2-121 Meter Indicator 4
2-131 Hex Head Bolt 4
2-143 Hex Set Screw 10
2-145 Hexagon 1
2-166 Spring Pin 3
2-167 Indicated Zero with Screw 2
2-168 Oil Ball 5
2-169 Hex Head Bolt 4
2-170 Washer 4
2-171 Hex Set Screw 10
2-172 Hex Head Bolt 4
2-173 Spring Washer 4
2-174 Hex Set Screw 2
2-175 Hex Set Screw 1
2-176 Hex Set Screw 2
