SKU 98733 For technical questions, please call 1-800-444-3353. Page 12
USER-MAINTENANCE
INSTRUCTIONS
Procedures not specically
explained in this manual
must be performed only by a
qualied technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION: Always
disconnect Nailer from its
compressed air supply and
safely discharge any residual
air pressure in the tool before
performing any inspection,
maintenance, or cleaning
procedures.
TO PREVENT SERIOUS
INJURY FROM TOOL
FAILURE: Do not use
damaged equipment. If
abnormal noise, vibration,
or leaking air occurs, have
the problem corrected before
further use.
TO PREVENT EXPLOSION:
Lubricate tool only with
specied lubricants.
Lubricate the air inlet using
only pneumatic tool oil.
Lubricate internal mechanism
using only white lithium
grease. Other lubricants may
damage the mechanism and
may be highly ammable,
causing an explosion.
Cleaning, Maintenance, and
Lubrication
Note: Anytime inspection, maintenance
and cleaning are done:
Disconnect the Framing Nailer 1.
from its air supply.
Empty Magazine (71) completely.2.
Try to re the Nailer into a piece of 3.
scrap wood or ooring to ensure
that it is disconnected and inca-
pable of ring any nails.
Always leave Magazine open dur-4.
ing maintenance. The Magazine
is spring-loaded and may cause
parts or a nail to y out of Nailer
BEFORE EACH USE, inspect gener-5.
al condition of Framing Nailer. Check
for loose screws, misalignment or
binding of moving parts, jammed
nails, cracked or broken parts, dam-
aged air supply hose, and any other
condition that may affect the safe
operation of this tool. If abnormal
noise or vibration occurs, immediately
disconnect the Nailer from its com-
pressed air supply source and have
the problem corrected before further
use. Do not use damaged equipment.
PERIODICALLY6. , use a premium
quality, lightweight oil to lubricate all
moving parts.
When necessary, wipe with damp 7.
cloth.
Store in a clean, dry and safe location 8.
out of reach of children.
All maintenance, service or repairs 9.
not listed in this manual are only
to be attempted by a qualied ser-
vice technician.
