SKU 98733 For technical questions, please call 1-800-444-3353. Page 14
Part Description
1 Screw
2 Spring Washer
3 Bushing
4 Exhaust Cover
5 Seal
6 Screw
7 Spring Washer
8A Cylinder Cap
9A O-ring sealing
10 Washer
11 Valve Seat
12 Spring
13 O-Ring (M57.5 x 3.6)
14 O-Ring (M72.4 x 3.5)
15 Valve
16 Screw
17 Cylinder Seal
18 Collar
19 O-Ring (M54.4 x 4)
20 Piston
21 Cylinder
22 O-Ring (M67 x 3)
23 O-Ring (M60.25 x 2.5)
24 Restrictive Seal
25 O-Ring (M97.5 x 3.5)
26 Bumper A
27 Bumper B
28 Body
Part Description
29 O-Ring (M62.3 x1.8)
30 Nose
31 Spring Washer
32 Screw
33 Spring
34 Safety Bracket
35 Screw
36 Bushing
37 Safety
38 Washer
39 Screw
40 Rubber Cover
41 Spring Pin
42 Safety Guide
43 O-Ring (M18.4 x 2.4)
44 O-Ring (M20.3 x 1.5)
45 Valve Set
46 O-Ring (M9.5 x 1.9)
47 O-Ring (M10.3 x 1.9)
48A Trigger Valve Head
49 O-Ring (M12.8 x 1.9)
50 Spring
51 O-Ring (M5.5 x 1.5)
52 Trigger Valve Stem
53 O-Ring (M24.8 x 2)
54 Trigger Valve Guide
55 Trigger Spring
56 Trigger
Part Description
57 Seal
58 Pin
59 Rail
60 Washer
61 Nut
62 Washer
63 Coil Spring
64 Pin
65 Bushing
66 Screw
67 Block
68 Washer
69 Feeder Shoe
70 Screw
71 Magazine
72 Screw
73 Support
74 Nut
75 Lock
76 Torsion Spring
77 Bushing
78 Nut
79 Nut
80 Soft Grip Sleeve
81 O-Ring (65.4x2.5)
82 End Cap
83 Air Plug
PARTS LIST
REV 09g
